Multi-Phase Project: Phase
Charleroi Locks & Dam - River Chamber Completion
The modernization effort at this site will ultimately result in the construction of two new 84-feet wide by 720-feet long chambers to replace the existing 56-feet wide lock currently in operation.
location
Monongahela
,
Pennsylvania
ESTIMATED VALUE
$240.8M
owner
US Army Corps of Engineers, Pittsburgh District
Completion date
general contractor
Trumbull-Brayman, Joint Venture
Market
Locks & Dams
Multi-Phase Project: Phase
Charleroi Locks & Dam - River Chamber Completion
The US Army Corps of Engineers (USACE), Pittsburgh District is the Owner of the Charleroi Locks and Dam 4 River Chamber Completion Project, located on the Monongahela River in Monessen, PA. The River Chamber Completion Project consists of a Base Bid and Five Options. The modernization effort at this site will ultimately result in the construction of two new 84-feet wide by 720-feet long chambers to replace the existing 56-feet wide lock currently in operation.
Performed as a Joint Venture by Trumbull Corporation and Brayman Construction Corporation, TBJV is currently building the Base Bid, Option 1, and Option 2. With these options, TBJV will construct the new middle wall monoliths from M-1 to M-16.
